The fleet

Super Large Jet

Bombardier Global 5000

Bombardier Global 5000

Range

5,200 NM

Cruise speed

511 kts

Seats

13

Technical Specifications

General information

Model nameGlobal 5000
ManufacturerBombardier
Aircraft categorysuper large jet
ICAO DesignatorGL5T
Start/End of Production2005 - 2018
Number of pilot(s)2

Performances

Range (with IFR reserves)5200 NM (9630 km)
Ferry range5475 NM (10140 km)
Cruise speed511 kts (946 km/h)
Max Operating Speed – VMO340 KIAS
Max Mach Operating Speed - MMOMach 0.89
Long-Range Cruise Speed - LRC488 KTAS
Approach Speed107 kts
Takeoff Distance1690 m
Average Landing Distance670 m
Rate of Climb3450 ft/min
Service Ceiling51000 ft
Thrust14750 lbf

Aircraft technology

Engine typeTurbofan
Engine(s)2
AvionicsHoneywell Primus 2000XP

Dimensions and capacity

Aircraft length29.5 m
Aircraft height7.8 m
Wing span28.7 m
Cabin height1.91 m (6.25 ft)
Cabin length12.95 m (42.47 ft)
Cabin width2.49 m (8.17 ft)
Baggage volume5.5 m3
Seats (standard config)13
Seats (max)19
Suitcases16
Carry-on luggage14
Maximum payload3250 kg
Maximum TakeOff Weight - MTOW42000 kg
Maximum Landing Weight - MLW35700 kg
Fuel capacity22200 L

FAQ

Is the Global 5000 able to use smaller airports?

It is certified for steep approaches, so it can serve challenging airports, London City among them, which combines a short runway with a steep descent. It needs around 1,690 m to take off and about 670 m to land, varying with weight and weather. That brings airports such as Sion within reach, but very short strips such as Gstaad (Saanen) are beyond its limits.

Which is better for my trip, the Global 5000 or the Dassault Falcon 7X?

Both are large-cabin jets built for long distances. The Global 5000 seats 13 in its standard layout and the Falcon 7X seats 14. The Falcon also flies further, about 5,950 nautical miles against 5,200, and it can use short runways, Gstaad (Saanen) included, that are closed to the Global 5000. The right choice depends on your route and party size.

Where does the Global 5000 sit among Bombardier's larger Global jets?

The Global 6000 followed the 5000, adding range to about 6,000 nautical miles along with newer avionics and interior updates. The Global 7500 (originally named the Global 7000) is larger again, with four cabin zones and 7,700 nautical miles of range, enough for New York to Hong Kong. Bombardier's Global 8000 keeps a similar cabin to the 7500 and extends range to about 8,000 nautical miles. For charter, the Global 5000 covers most intercontinental trips, while its successors suit missions that need more distance or a larger cabin.

How far can a Global 5000 fly before it needs fuel?

Its range with IFR reserves is 5,200 nautical miles (9,630 km). Munich and New York, or London and Delhi, are within a single leg, and most intercontinental routes can be flown without a fuel stop. On the longest sectors, passenger numbers and winds decide whether a stop is needed, and your advisor will confirm this when quoting.

Gallery

Bombardier Global 5000, cabin
Bombardier Global 5000, photograph
Bombardier Global 5000, cabin
Bombardier Global 5000, cabin

Figures are published manufacturer data, shown for illustration only. Images are generated for this concept and show the Global 5000 type, not a specific aircraft. Bombardier and Global 5000 are trademarks of their owner, used only to identify the aircraft.
