VIP Airliner
Embraer Lineage 1000
Range
4,093 NM
Cruise speed
470 kts
Seats
13
Technical Specifications
General information
| Model name | Lineage 1000 |
|---|---|
| Manufacturer | Embraer |
| Aircraft category | VIP airliner |
| ICAO Designator | E190 |
| Start/End of Production | 2009 - 2013 |
| Number of pilot(s) | 2 |
Performances
| Range (with IFR reserves) | 4093 NM (7580 km) |
|---|---|
| Ferry range | 4600 NM (8519 km) |
| Cruise speed | 470 kts (870 km/h) |
| Max Operating Speed – VMO | 320 KIAS |
| Max Mach Operating Speed - MMO | Mach 0.82 |
| Long-Range Cruise Speed - LRC | 454 KTAS |
| Approach Speed | 110 kts |
| Takeoff Distance | 1950 m |
| Average Landing Distance | 721 m |
| Service Ceiling | 41000 ft |
| Thrust | 18500 lbf |
Aircraft technology
| Engine type | Turbofan |
|---|---|
| Engine(s) | 2 x General Electric CF34-10E |
| Avionics | Honeywell Primus Epic |
Dimensions and capacity
| Aircraft length | 36.24 m |
|---|---|
| Aircraft height | 10.57 m |
| Wing span | 28.72 m |
| Cabin height | 1.98 m (6.5 ft) |
| Cabin length | 25.68 m (84.25 ft) |
| Cabin width | 2.69 m (8.83 ft) |
| Baggage volume | 12.5 m3 |
| Seats (standard config) | 13 |
| Seats (max) | 19 |
| Suitcases | 26 |
| Carry-on luggage | 19 |
| Maximum payload | 4366 kg |
| Maximum TakeOff Weight - MTOW | 54500 kg |
| Maximum Landing Weight - MLW | 45800 kg |
| Fuel capacity | 27236 L |
FAQ
Does the Lineage 1000 fly further than the Legacy 650?
It does, though the margin is modest. With IFR reserves the Lineage 1000 is rated for 7,580 km (4,093 nautical miles), against about 7,223 km for the Legacy 650, another Embraer aircraft. The bigger difference is the cabin: the Lineage is an airliner-based aircraft with five zones and room for up to 19 passengers.
What is the seating capacity of the Lineage 1000?
Standard layouts seat 13, and the maximum is 19. The cabin is divided into five zones for work, dining, leisure and sleep, and it offers close to 70 square metres of floor space, which Embraer describes as a flying apartment. Baggage capacity of 12.5 cubic metres takes around 26 suitcases and 19 carry-on bags.
How fast does the Lineage 1000 cruise?
It cruises at 470 knots (870 km/h), quick for a VIP airliner, with a maximum operating speed of Mach 0.82 and a ceiling of 41,000 feet. That makes it a practical choice for long transcontinental flights with a large group on board.
How far can the Lineage 1000 fly?
With IFR reserves it covers 4,093 nautical miles (7,580 km), and its ferry range for positioning without passengers is 4,600 nautical miles. That puts New York to Rome and São Paulo to Miami within a single flight, which suits intercontinental business travel.
What sets the Lineage 1000 cabin apart?
Five zones give dedicated space for meetings, formal dining and leisure, plus a private bedroom, a layout that distinguishes it from conventional business jets. The main baggage compartment holds over 9 cubic metres, with further lockers outside. Stabilisation and turbulence detection systems also help keep the ride comfortable.
Gallery
Figures are published manufacturer data, shown for illustration only. Images are generated for this concept and show the Lineage 1000 type, not a specific aircraft. Embraer and Lineage 1000 are trademarks of their owner, used only to identify the aircraft.
