Super Midsize Jet
Hawker 4000
Range
3,100 NM
Cruise speed
470 kts
Seats
8
History
The Hawker 4000 was the company's first aircraft in the super midsize class and its flagship business jet. Its fuselage is built from carbon fibre and other composite materials, chosen to save weight and improve structural efficiency, and it was designed to take on established rivals in a growing part of the market. Production ran from 2008 to 2013.
Two Pratt & Whitney Canada PW308A engines gave it better performance and fuel efficiency than older designs, while the Honeywell Primus Epic flight deck and a roomy cabin suited it to transcontinental work. Even so, the aircraft struggled commercially, and it remained Hawker's main attempt at the super midsize market before Textron eventually acquired the company.
Technical Specifications
General information
| Model name | Hawker 4000 |
|---|---|
| Manufacturer | Hawker |
| Aircraft category | super midsize jet |
| ICAO Designator | HA4T |
| Start/End of Production | 2008 - 2013 |
| Number of pilot(s) | 2 |
Performances
| Range (with IFR reserves) | 3100 NM (5741 km) |
|---|---|
| Ferry range | 3283 NM (6080 km) |
| Cruise speed | 470 kts (870 km/h) |
| Max Operating Speed – VMO | 350 KIAS |
| Max Mach Operating Speed - MMO | Mach 0.84 |
| Long-Range Cruise Speed - LRC | 447 KTAS |
| Approach Speed | 115 kts |
| Takeoff Distance | 1545 m |
| Average Landing Distance | 754 m |
| Rate of Climb | 3415 ft/min |
| Service Ceiling | 45000 ft |
| Thrust | 6904 lbf |
Aircraft technology
| Engine type | Turbofan |
|---|---|
| Engine(s) | 2 x Pratt & Whitney Canada PW308A |
| Avionics | Honeywell Primus Epic |
Dimensions and capacity
| Aircraft length | 21.18 m |
|---|---|
| Aircraft height | 6.02 m |
| Wing span | 18.84 m |
| Cabin height | 1.83 m (6.0 ft) |
| Cabin length | 7.62 m (25.0 ft) |
| Cabin width | 1.98 m (6.5 ft) |
| Baggage volume | 3.26 m3 |
| Seats (standard config) | 8 |
| Seats (max) | 14 |
| Suitcases | 13 |
| Carry-on luggage | 10 |
| Maximum payload | 1145 kg |
| Maximum TakeOff Weight - MTOW | 17917 kg |
| Maximum Landing Weight - MLW | 15195 kg |
| Fuel capacity | 8078 L |
FAQ
Can the Hawker 4000 match the Citation X for speed?
No. The Citation X cruises at 514 knots (952 km/h), against 470 knots (870 km/h) for the Hawker 4000. On range the two are almost level: the Hawker is rated for 5,741 km and the Citation X for about 5,762 km. The speed gap saves the most time on longer sectors. The Hawker's maximum operating speed is Mach 0.84, and its service ceiling is 45,000 feet.
How many passengers fit in a Hawker 4000?
The standard layout seats eight in two club-four groupings. High-density layouts take up to 14, at the cost of personal space and baggage room. The cabin is 7.62 metres long, 1.98 metres wide and 1.83 metres high, and seven large windows per side let in plenty of daylight.
How far can the Hawker 4000 fly nonstop?
With IFR reserves it covers 3,100 nautical miles (5,741 km), so Paris to Dubai and London to New York are both possible without a fuel stop. For positioning flights without passengers, the ferry range extends to 3,283 nautical miles (6,080 km).
What does the composite fuselage mean for passengers?
The carbon-fibre fuselage, rare among jets in this class, keeps weight down without losing strength. That helps the climb, as reaching 41,000 feet takes less than 19 minutes, and it improves fuel efficiency. The baggage compartment is pressurised and reachable during flight. The construction also raised manufacturing costs, which hurt sales before production ended in 2013.
Gallery
Figures are published manufacturer data, shown for illustration only. Images are generated for this concept and show the 4000 type, not a specific aircraft. Hawker and 4000 are trademarks of their owner, used only to identify the aircraft.
